Question 6. A portable floor crane in a garage is used to lift a 100 kg engine, see Fig. 6. For the position shown determine the magnitude of the force supported by the pin at and the oil pressure required in the hydraulic cylinder unit, A, if the piston diameter of the hydraulic cylinder is 80 mm. [Ans - 2982 N, 7.82 bar ] 1050 mm - 450 B 30 Fig. 6 150 mm

Consider the radial tracking problem of a CD player lens. The block diagram for such a system is shown in the figure.what's a,b,c, and d? Consider the radial tracking problem of a CD player lens. The block diagram for such a system is shown in the figure. Here \( y \) is the radial position, \( d \) is the external disturbance on the position and \( u \) is the control signal for the lens. Transfer function for the CD lens between the control \( u \) and the radial position is estimated as \( \mathrm{G}_{\mathrm{p}}(\mathrm{s})=\frac{-40000 \mathrm{~s}+2.5 \cdot 10^{9}}{\mathrm{~s}^{2}+200 \mathrm{~s}+95000} \). a) Suppose a \( \mathrm{P} \) control strategy is used, i.e., \( \mathrm{G}_{\mathrm{c}}(\mathrm{s})=\mathrm{K} \). Show that if \( \mathrm{K} \) is increased from zero, the system will go unstable after a certain \( \mathrm{K} \) value. Find that \( \mathrm{K} \) value. b) Find the steady state error for a unit step disturbance input for the \( \mathrm{K} \) value you found in part (a). c) Use \( \mathrm{G}_{\mathrm{c}}(\mathrm{s})=0.2 \frac{1+0.002 \mathrm{~s}}{1+0.1 \mathrm{~s}} \frac{1+0.00067 \mathrm{~s}}{1+0.0002 \mathrm{~s}} \) as a controller. Plot the unit disturbance response of the system using MATLAB, and estimate the settling time and the steady state value from the plot. d) One of the causes of disturbance in CD players is the eccentricity of the CD, which results in a sinusoidal disturbance on the radial position. Using MATLAB, simulate the disturbance response of the system for \( \mathrm{d}(\mathrm{t})=0.1 \sin (10 \mathrm{t}) \). Hint: You can try using MATLAB Control System Toolbox functions feedback, step, tf, etc. in your solutions.

A beam of initially unpolarized light passes through a sequence of the polarizers. The angle iz between the axes of the first and second polarizers is 16.1", and the angle between the axes of the second and third polarizers is 52.9". D What is the ratio of the intensity of light emerging from the third polarizer to the intensity to of light incident on the tirst polarizer? What is the ratio of the intensity 13 of light emerging from the third polarizer to the intensity lo of light incident on the first polarizer? 13 70

thanks The table shows how 10 students were ranked according to their achievements in both the laboratory and lecture portions of a biology course. Find the following (Use 2 decimal places for 1 & 2) coefficient of rank correlation coefficient of determination value of y if x=11 LAB, X LEC, y 8 9 32 10 5 Answer in 1 decimal place 9 10 1 78 10 7 - M - 2 6

Part B - Ideal op amp circuits with a voltage source: part 2 For the circuit shown (Figure 1), determine the range (i.e., maximum and minimum values) of \( V_{2} \) so that the op amp operates in the linear region. Assume that \( R_{1}=6 \mathrm{k} \Omega, R_{2}=6 \mathrm{k} \Omega, R_{3}=35 \mathrm{k} \Omega \), and \( V_{c c}=15 \bar{V} \). Express your Part B - Ideal op amp circuits with a voltage source: part 2 For the circuit shown (Figure 1), determine the range (i.e., maximum and minimum values) of V2​ so that the op amp operates in the linear region. Assume that R1​=6kΩ,R2​=6kΩ,R3​=35kΩ, and Vcc​=15Vˉ. Express your answer in volts to two significant figures separated by a comma. X Incorrect; Try Again; 3 attempts remaining Part C - Ideal op amp circuits with voltage and current sources

1. A multipleprocessor consists of 100 processors, each capable of a peak execution rate of 2Gflops. What is the performance of the system as measured in Gflops when 10% of the code is sequential and 90% is parallelizable? 2. Is it possible to have a system efficiency (E) of greater than 100%? Discuss. 3. Parallelize the program of finding the sum of

Parallel computing can you help me solve problem them step by step I am learning as I go Problems 1-1. A multiprocessor consists of 100 proces multiprocessor consists of 100 processors, each capable of a peak execution rate of 2 Gflops. What is the performance of the system as measured in Gflops when 10% of the code is sequential and 90% is parallelizable? 1-2. Is it possible to have a system efficiency (E) of greater than 100%? Discuss. Combine the equation for Amdahl's law with the superlinear speedup analysis in Section 1.2.1 to obtain an equation for speedup given that some of a search has to be done sequentially 1-3.
