please answer as many ... thank you > Question 1 100 pts Design a controller for the LED labeled "E" in a 7 segment LED display to display digits 0-9 using the patterns shown in the figure. The LED will light up when Z equals 1. Z is a function of 4 variables, Z = fA.B.CD), where variable D is the least significant bit. 8 0 :23456789 LEHT HI HII 1 and 2. Find the Sum of Minterms and the Sum of Don't Cares. Z-m 0.2.79 D+Ed 10,11,12,13,14,15 3. Find the simplest Boolean SOP expression (SOP - Sum of Products) Format Note: Place this answer in order by the number of inputs to the AND gates. For example, to write WXY+Z + XZ+ZY: then answer Z+XY+XZ+WXY or Z+XZ+XY+WXY are in correct format order and will be marked correct and XY+WXY+Z+XZ will be marked wrong by the computer. So order the sum with the terms with the smallest number of variables first, the terms with highest number of variables last 2 = CD+B'D For the 74HC154 4 to 8 decoder Chip below fill in the most appropriate responses to make your controller X/Y 2P For the 74HC154 4 to 8 decoder Chip below fill in the most appropriate responses to make your controller X/Y 13 13 14 15 EN 14 Format Note: Your available inputs are A,B,C,D,GND and VCC 4. List the input connections to the X pins 1.2.4 and 8 (In that order) 5. List the connections to the EN pins 1 and 2 (In that order) 6. List which Y pins need to be wired to a logic gate 7. Which type of logic gate is needed to combine the outputs from Y to make Z Using two 3 to 8 decoders as shown below, fill in the most appropriate responses to make your controller. Use Chip 13 to 8 decoder for minterms o through 7, and Chip 2 for minterms 8 through 15. Chip 1 Chip 2 For the 3 to 8 decoder circuit, show the connections: Chip 1 (3 to 8 decoder): 8. List the Input connections to pins AB and C for Chip 1 (In that order) 9. List the connections to the enable pins G1,G2 and G3 for Chip 1 In that order) 10. List which output pins (0,1,2,3,4,5,6,7) need to be wired to a logic gate from Chip 1 Chip 2 (3 to 8 decoder): 11. List the input connections to the pins A, B and C for Chip 2 in that order) 12. List the connections to the enable pins G1,G2 and G3 for Chip 2 (In that order) 13. List which output pins (0,1,2,3,4,5,6,7) need to be wired to a logic gate from Chip 2 14. Which type of logic gate is needed to combine the outputs from both chips to make Z?
